Filter data in a data flow

Important

This page includes instructions for managing Azure IoT Operations components using Kubernetes deployment manifests, which is in PREVIEW. This feature is provided with several limitations, and shouldn't be used for production workloads.

See the Supplemental Terms of Use for Microsoft Azure Previews for legal terms that apply to Azure features that are in beta, preview, or otherwise not yet released into general availability.

Use the filter stage in a data flow to drop messages that match a condition. When a filter expression evaluates to true, the message is dropped. When the expression evaluates to false, the message passes through to the next stage.

You can define multiple filter rules. Each rule specifies input fields and a boolean expression. The rules use OR logic: if any rule evaluates to true, the message is dropped.

Configure a filter

Each filter rule has the following properties:

Property	Required	Description
`inputs`	Yes	List of field paths to read from the incoming message. Assigned positional variables: the first input is `$1`, the second is `$2`, and so on.
`expression`	Yes	Boolean expression evaluated against each message. If true, the message is dropped.
`description`	No	Human-readable description of the filter rule.

Use last known value

Append ? $last to an input to use the last known value when the field is missing from the current message. This approach is useful for sparse data where not every message contains every field.

Examples

Filter by a threshold

Drop messages where temperature is 20 or below:

Under Transform (optional), select Filter > Add.
Enter the following settings:

Setting Description

Filter condition temperature <= 20

Description Drop low temperature readings

In the filter condition field, enter @ or select Ctrl + Space to choose datapoints from a dropdown.
Select Apply.

Setting	Description
Filter condition	`temperature <= 20`
Description	Drop low temperature readings

{
  "operationType": "BuiltInTransformation",
  "builtInTransformationSettings": {
    "filter": [
      {
        "inputs": [
          "temperature"
        ],
        "expression": "$1 <= 20"
      }
    ]
  }
}

builtInTransformationSettings: {
  filter: [
    {
      inputs: [
        'temperature'
      ]
      expression: '$1 <= 20'
    }
  ]
}

builtInTransformationSettings:
  filter:
    - inputs:
        - temperature
      expression: "$1 <= 20"

Filter with last known value

Use the last known temperature value if the current message doesn't include it. Drop messages where the last known temperature is 20 or below:

In the filter condition field, enter @temperature ? $last <= 20.

{
  "operationType": "BuiltInTransformation",
  "builtInTransformationSettings": {
    "filter": [
      {
        "inputs": [
          "$source.temperature ? $last"
        ],
        "expression": "$1 <= 20"
      }
    ]
  }
}

builtInTransformationSettings: {
  filter: [
    {
      inputs: [
        'temperature ? $last'
      ]
      expression: '$1 <= 20'
    }
  ]
}

builtInTransformationSettings:
  filter:
    - inputs:
        - temperature ? $last
      expression: "$1 <= 20"

Filter with multiple conditions

Drop messages where the product of temperature and humidity is 100,000 or more:

In the filter condition field, enter @temperature * @humidity >= 100000.

{
  "operationType": "BuiltInTransformation",
  "builtInTransformationSettings": {
    "filter": [
      {
        "inputs": [
          "temperature.Value",
          "humidity.Value"
        ],
        "expression": "$1 * $2 >= 100000"
      }
    ]
  }
}

builtInTransformationSettings: {
  filter: [
    {
      inputs: [
        'temperature.Value'
        'humidity.Value'
      ]
      expression: '$1 * $2 >= 100000'
    }
  ]
}

builtInTransformationSettings:
  filter:
    - inputs:
        - temperature.Value
        - humidity.Value
      expression: "$1 * $2 >= 100000"

Filter with enriched data

If you configured an enrichment dataset, you can use enriched fields in filter conditions. For example, filter against a device-specific limit from a state store dataset:

Currently, enrichment-based filtering isn't available in the operations experience.

{
  "operationType": "BuiltInTransformation",
  "builtInTransformationSettings": {
    "datasets": [
      {
        "key": "device_limits",
        "inputs": [
          "$source.deviceId",
          "$context(device_limits).deviceId"
        ],
        "expression": "$1 == $2"
      }
    ],
    "filter": [
      {
        "inputs": [
          "temperature",
          "$context(device_limits).maxTemperature"
        ],
        "expression": "$1 <= $2"
      }
    ]
  }
}

builtInTransformationSettings: {
  datasets: [
    {
      key: 'device_limits'
      inputs: [
        '$source.deviceId'
        '$context(device_limits).deviceId'
      ]
      expression: '$1 == $2'
    }
  ]
  filter: [
    {
      inputs: [
        'temperature'
        '$context(device_limits).maxTemperature'
      ]
      expression: '$1 <= $2'
    }
  ]
}

builtInTransformationSettings:
  datasets:
    - key: device_limits
      inputs:
        - $source.deviceId
        - $context(device_limits).deviceId
      expression: "$1 == $2"
  filter:
    - inputs:
        - temperature
        - $context(device_limits).maxTemperature
      expression: "$1 <= $2"

This example drops messages where the temperature exceeds the device-specific maximum from the state store.

Multiple filter rules

You can define multiple filter rules. All rules use OR logic: if any rule evaluates to true, the message is dropped:

Under Transform (optional), select Filter > Add multiple times to add additional filter rules.

{
  "operationType": "BuiltInTransformation",
  "builtInTransformationSettings": {
    "filter": [
      {
        "inputs": ["temperature"],
        "expression": "$1 <= 20",
        "description": "Drop low temperatures"
      },
      {
        "inputs": ["humidity"],
        "expression": "$1 >= 80",
        "description": "Drop high humidity readings"
      }
    ]
  }
}

builtInTransformationSettings: {
  filter: [
    {
      inputs: ['temperature']
      expression: '$1 <= 20'
      description: 'Drop low temperatures'
    }
    {
      inputs: ['humidity']
      expression: '$1 >= 80'
      description: 'Drop high humidity readings'
    }
  ]
}

builtInTransformationSettings:
  filter:
    - inputs:
        - temperature
      expression: "$1 <= 20"
      description: Drop low temperatures
    - inputs:
        - humidity
      expression: "$1 >= 80"
      description: Drop high humidity readings
